Nitrogenema II™
Inert Gas Isolator - Low Moisture, Low Oxgyen
The Nitrogenema II™ offers a stable dry interior containment solution using a continuous nitrogen purge. Nitrogen helps eliminate moisture and keeps the interior workspace dry to protect sensitive materials. Designed using American Glovebox Society (AGS) guidelines, the Nitrogenema II™ aims to minimize arm, wrist, and shoulder fatigue. This unit’s features include HEPA filtration, a one-way check valve, and the ability to connect to a house exhaust system using a thimble connection.
Process
Dispensing/weighing pyrophoric substances, reactive substances, and other materials that react adversely to oxygen mixing.
Containment
This unit protects your process or application by nearly eliminating all moisture or oxygen with the flow of inert gas.
Design
Quick purge system reduces the amount it time it takes to purge the interior. Reduces downtime for cleaning procedures.
Benefits
Applications
The Nitrogenema II™ is designed for handling pyrophoric and reactive substances. It’s ideal for materials sensitive to oxygen. Protection is paramount in diverse applications.
Structural Materials
Constructed of white polypropylene with clear acrylic panels. A chemically resistant phenolic base contains spills. Static dissipative materials are optional.
Quick Purge System
Equipped with a quick-purge valve for efficiency. Allows rapid purging for campaign switches or cleaning. Designed to minimize downtime seamlessly.
HEPA Filtration
Boasts primary and secondary HEPA filters. The design prevents exhaust system contamination. An interior panel ensures safe filter replacements.
Inert Gas Workspace
The workspace is engineered for low humidity and oxygen. It ensures a stable environment for reactive materials. Safety and stability are key design elements.
Standard Sizes
Offered in widths of 3′, 4′, and 5′ with two exhaust options. Units maintain a 28” depth and 29” height. Custom dimensions are available based on need.
Useful Videos
Additional Resources
Over the years, we built an inventory of unique enclosures engineered to handle specific tasks. To offer you a better experience we have gathered these enclosures on one page. Simply search by the task or equipment to find matching enclosures.
SEARCH CONTAINMENT BY APPLICATION
Over the years, we built an inventory of unique enclosures engineered to handle specific tasks. To offer you a better experience we have gathered these enclosures on one page. Simply search by the task or equipment to find matching enclosures.
Process
Dispensing and weighing pyrophoric substances, reactive substances, substances that react with oxygen mixing.
Containment
Capable of protecting your process by nearly eliminating all moisture or oxygen with the flow of inert gas.
Design
Time is crucial in your lab, so we have put engineered controls in place to minimize the purge time.
Low Moisture, Low Oxygen
Safety
The Nitrogenema IITM is a product that offers both, the operator and application, the highest level of containment available. HEPA filtration, a one way check valve, and the ability to connect to a house exhaust system all contribute the high level of containment and put this enclosure in a class of its own.
Design
Using AGS (American Glovebox Society) guidelines, the Nitrogenema IITM is designed with a 30” external depth and comfortable 10” oval glove ports, minimizing arm, wrist, and shoulder fatigue for lab technicians.
PHENOLIC BASE
The chemically resistant base is dished to contain spills and coated with a phenolic resin to protect the work surface from harmful chemicals.
FRONT LIFT DOOR
The pneumatic-assisted hinged door opens creating a large face opening in the glovebox to facilitate equipment loading and decontamination.
INTERIOR HEPA FILTER
The pneumatic-assisted hinged door opens creating a large face opening in the glovebox to facilitate equipment loading and decontamination.
STRUCTURAL MATERIALS
This unit gives the option of using static dissipative acrylic (END Series), acrylic (ENP Series), or glass (ENG Series) for the viewing panels. The superstructure is built using white polypropylene.
Sizing & Options
Available in 3’, 4’ and 5’ with two exhaust options to best suite your needs. All units are 28” internal depth and 29” internal height.
Question or need a quote?
Contact us using our online form, live chat, or call 1-800-849-3429. We're here to help you find the solution you need.
Contact Our Experts
SEARCH CONTAINMENT BY APPLICATION
Build Options
| Product Type | Style | Material | Ext. Width | Ext. Depth | Internal Height | Base | Exhaust / Filtration | Voltage / Light | Options |
|---|---|---|---|---|---|---|---|---|---|
| E – Enclosure | N – Inert Gas/ Controlled Environment | D – Static Dissipative Acrylic | 36" | 28" (END Only) | 28" | A – Standard |
C – No Fan/Filter (END Only) |
K – 110-120v 50-60 Hz (END Only) |
0 – Left Access Door (END Only) |
| P – Poly (Acrylic viewing panels) | 48" |
30" (ENP & ENG Only) |
D – No Fan/ No Filter (END Only) |
L – 220-240v 50-60 Hz (END Only) |
0 – Left Pass Thru (ENP & ENG Only) |
||||
| G – Poly (Glass viewing panels) | 60”" | S – No Fan/Safe Change Out Filter (Only ENP & ENG) | W – Cool White Light (ENP & ENG Only) |
1 – Right Access
Door (END Only) |
|||||
| WY – White & Yellow Light (ENP & ENG Only) | 1 – Right Pass Thru (ENP & ENG Only) | ||||||||
| 2 – Left Access Door/Right Pass Thru (END Only) | |||||||||
| 3 – Right Access Door/Left Pass Thru (END Only) |
Accessories
| Add-Ons | ||
|---|---|---|
| Berkshire Cleaning Kit | Contact Flow Sciences for kit description |
|
