Top Mount Series Specs

Dimensions & Face Velocity Requirements for Standard ETA Series Enclosures

Dimensions

Imperial Units (Inches)

ETA242424 DIMENSIONS (INCHES)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA242424	REGULAR	SINGLE	23.75	24.00	42.56	22.04	20.55	24.28	22.04	12.50
	MESH	SINGLE	23.75	24.00	40.56	22.04	20.55	24.28	22.04	12.50
	NONE	SINGLE	23.75	24.00	40.51	22.04	20.55	24.28	22.04	12.50
		NONE	23.75	24.00	31.14	22.04	20.55	24.28	22.04	12.50

ETA243024 DIMENSIONS (INCHES)
MODEL	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA243024	REGULAR	SINGLE	23.75	30.00	42.56	22.04	26.55	24.25	22.04	9.50
	MESH	SINGLE	23.75	30.00	40.56	22.04	26.55	24.25	22.04	9.50
	NONE	SINGLE	23.75	30.00	40.51	22.04	26.55	24.25	22.04	9.50
		NONE	23.75	30.00	31.14	22.04	26.55	24.25	22.04	9.50

ETA362424 DIMENSIONS (INCHES)
MODEL	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA362424	REGULAR	SINGLE	35.75	24.00	44.31	34.04	20.55	24.28	34.04	12.50
		DUAL	35.75	24.00	53.29	34.04	20.55	24.28	34.04	12.50
	MESH	SINGLE	35.75	24.00	42.31	34.04	20.55	24.28	34.04	12.50
		DUAL	35.75	24.00	51.29	34.04	20.55	24.28	34.04	12.50
	NONE	SINGLE	35.75	24.00	40.51	34.04	20.55	24.28	34.04	12.50
		DUAL	35.75	24.00	49.71	34.04	20.55	24.28	34.04	12.50
		NONE	35.75	24.00	31.14	34.04	20.55	24.28	34.04	12.50

ETA363024 DIMENSIONS (INCHES)
MODEL	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA363024	REGULAR	SINGLE	35.75	30.00	42.56	34.04	26.55	24.25	34.04	9.50
		DUAL	35.75	30.00	51.54	34.04	26.55	24.25	34.04	9.50
	MESH	SINGLE	35.00	30.00	40.56	34.04	26.55	24.25	34.04	9.50
		DUAL	35.75	30.00	49.54	34.04	26.55	24.25	34.04	9.50
	NONE	SINGLE	35.75	30.00	40.51	34.04	26.55	24.25	34.04	9.50
		DUAL	35.75	30.00	49.70	34.04	26.55	24.25	34.04	9.50
		NONE	35.75	30.00	31.14	34.04	26.55	24.25	34.04	9.50

ETA482424 DIMENSIONS (INCHES)
MODEL	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA482424	REGULAR	SINGLE	47.75	24.00	44.31	46.04	20.55	24.28	46.04	12.50
		DUAL	47.75	24.00	53.29	46.04	20.55	24.28	46.04	12.50
	MESH	SINGLE	47.75	24.00	42.31	46.04	20.55	24.28	46.04	12.50
		DUAL	47.75	24.00	51.31	46.04	20.55	24.28	46.04	12.50
	NONE	SINGLE	47.75	24.00	40.51	46.04	20.55	24.28	46.04	12.50
		DUAL	47.75	24.00	49.70	46.04	20.55	24.28	46.04	12.50
		NONE	47.75	24.00	31.14	46.04	20.55	24.28	46.04	12.50

ETA483024 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA483024	REGULAR	SINGLE	47.75	30.00	44.31	46.04	26.55	24.25	46.04	9.50
		DUAL	47.75	30.00	53.29	46.04	26.55	24.25	46.04	9.50
	MESH	SINGLE	47.75	30.00	42.31	46.04	26.55	24.25	46.04	9.50
		DUAL	47.75	30.00	51.29	46.04	26.55	24.25	46.04	9.50
	NONE	SINGLE	47.75	30.00	40.51	46.04	26.55	24.25	46.04	9.50
		DUAL	47.75	30.00	49.70	46.04	26.55	24.25	46.04	9.50
		NONE	47.75	30.00	31.14	46.04	26.55	24.25	46.04	9.50

ETA603027 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA603027	REGULAR	SINGLE	59.75	30.00	46.93	58.04	26.55	26.90	58.04	12.50
		DUAL	59.75	30.00	55.91	58.04	26.55	26.90	58.04	12.50
	MESH	SINGLE	59.75	30.00	44.93	58.04	26.55	26.90	58.04	12.50
		DUAL	59.75	30.00	53.91	58.04	26.55	26.90	58.04	12.50
	NONE	SINGLE	59.75	30.00	43.35	58.04	26.55	26.90	58.04	12.50
		DUAL	59.75	30.00	52.32	58.04	26.55	26.90	58.04	12.50
		NONE	59.75	30.00	33.76	58.04	26.55	26.90	58.04	12.50

ETA722427 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA722427	REGULAR	SINGLE	71.75	24.00	46.85	70.04	20.55	26.90	70.04	12.50
		DUAL	71.75	24.00	55.91	70.04	20.55	26.90	70.04	12.50
	MESH	SINGLE	71.75	24.00	44.85	70.04	20.55	26.90	70.04	12.50
		DUAL	71.75	24.00	53.91	70.04	20.55	26.90	70.04	12.50
	NONE	SINGLE	71.75	24.00	43.35	70.04	20.55	26.90	70.04	12.50
		DUAL	71.75	24.00	52.41	70.04	20.55	26.90	70.04	12.50
		NONE	71.75	24.00	33.76	70.04	20.55	26.90	70.04	12.50

ETA963027 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA963027	REGULAR	SINGLE	95.75	30.00	46.93	94.04	26.55	26.90	94.04	12.50
		DUAL	95.75	30.00	55.91	94.04	26.55	26.90	94.04	12.50
	MESH	SINGLE	95.75	30.00	44.93	94.04	26.55	26.90	94.04	12.50
		DUAL	95.75	30.00	53.91	94.04	26.55	26.90	94.04	12.50
	NONE	SINGLE	95.75	30.00	43.13	94.04	26.55	26.90	94.04	12.50
		DUAL	95.75	30.00	52.33	94.04	26.55	26.90	94.04	12.50
		NONE	95.75	30.00	33.76	94.04	26.55	26.90	94.04	12.50

ETA602427 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA602427	REGULAR	SINGLE	59.75	24.00	46.85	58.04	20.55	26.91	58.04	12.50
		DUAL	59.75	24.00	55.91	58.04	20.55	26.91	58.04	12.50
	MESH	SINGLE	59.75	24.00	44.85	58.04	20.55	26.91	58.04	12.50
		DUAL	59.75	24.00	53.91	58.04	20.55	26.91	58.04	12.50
	NONE	SINGLE	59.75	24.00	43.35	58.04	20.55	26.91	58.04	12.50
		DUAL	59.75	24.00	52.41	58.04	20.55	26.91	58.04	12.50
		NONE	59.75	24.00	33.76	58.04	20.55	26.91	58.04	12.50

ETA723027 Dimensions (inches)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA723027	REGULAR	SINGLE	71.75	30.00	46.93	70.04	26.55	26.90	70.04	12.50
		DUAL	71.75	30.00	55.91	70.04	26.55	26.90	70.04	12.50
	MESH	SINGLE	71.75	30.00	44.93	70.04	26.55	26.90	70.04	12.50
		DUAL	71.75	30.00	53.91	70.04	26.55	26.90	70.04	12.50
	NONE	SINGLE	71.75	30.00	43.35	70.04	26.55	26.90	70.04	12.50
		DUAL	71.75	30.00	52.32	70.04	26.55	26.90	70.04	12.50
		NONE	71.75	30.00	33.76	70.04	26.55	26.90	70.04	12.50

Metric Units (MM)

ETA242424 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA242424	REGULAR	SINGLE	603	610	1081	560	522	617	560	318
	MESH	SINGLE	603	610	1030	560	522	617	560	318
	NONE	SINGLE	603	610	1029	560	522	617	560	318
		NONE	603	610	791	560	522	617	560	318

ETA243024 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA243024	REGULAR	SINGLE	603	762	1081	560	674	616	560	241
	MESH	SINGLE	603	762	1030	560	674	616	560	241
	NONE	SINGLE	603	762	1029	560	674	616	560	241
		NONE	603	762	791	560	674	616	560	241

ETA362424 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA362424	REGULAR	SINGLE	908	610	1125	865	522	617	865	318
		DUAL	908	610	1354	865	522	617	865	318
	MESH	SINGLE	908	610	1075	865	522	617	865	318
		DUAL	908	610	1303	865	522	617	865	318
	NONE	SINGLE	908	610	1029	865	522	617	865	318
		DUAL	908	610	1263	865	522	617	865	318
		NONE	908	610	791	865	522	617	865	318

ETA363024 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA363024	REGULAR	SINGLE	908	762	1081	865	674	616	865	241
		DUAL	908	762	1309	865	674	616	865	241
	MESH	SINGLE	889	762	1030	865	674	616	865	241
		DUAL	908	762	1258	865	674	616	865	241
	NONE	SINGLE	908	762	1029	865	674	616	865	241
		DUAL	908	762	1262	865	674	616	865	241
		NONE	908	762	791	865	674	616	865	241

ETA482424 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA482424	REGULAR	SINGLE	1213	610	1125	1169	522	617	1169	318
		DUAL	1213	610	1354	1169	522	617	1169	318
	MESH	SINGLE	1213	610	1075	1169	522	617	1169	318
		DUAL	1213	610	1303	1169	522	617	1169	318
	NONE	SINGLE	1213	610	1029	1169	522	617	1169	318
		DUAL	1213	610	1262	1169	522	617	1169	318
		NONE	1213	610	791	1169	522	617	1169	318

ETA483024 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA483024	REGULAR	SINGLE	1213	762	1125	1169	674	616	1169	241
		DUAL	1213	762	1354	1169	674	616	1169	241
	MESH	SINGLE	1213	762	1075	1169	674	616	1169	241
		DUAL	1213	762	1303	1169	674	616	1169	241
	NONE	SINGLE	1213	762	1029	1169	674	616	1169	241
		DUAL	1213	762	1262	1169	674	616	1169	241
		NONE	1213	762	791	1169	674	616	1169	241

ETA602427 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA602427	REGULAR	SINGLE	1518	610	1190	1474	522	684	1474	318
		DUAL	1518	610	1420	1474	522	684	1474	318
	MESH	SINGLE	1518	610	1139	1474	522	684	1474	318
		DUAL	1518	610	1369	1474	522	684	1474	318
	NONE	SINGLE	1518	610	1101	1474	522	684	1474	318
		DUAL	1518	610	1331	1474	522	684	1474	318
		NONE	1518	610	858	1474	522	684	1474	318

ETA603027 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA603027	REGULAR	SINGLE	1518	762	1192	1474	674	683	1474	318
		DUAL	1518	762	1420	1474	674	683	1474	318
	MESH	SINGLE	1518	762	1141	1474	674	683	1474	318
		DUAL	1518	762	1369	1474	674	683	1474	318
	NONE	SINGLE	1518	762	1101	1474	674	683	1474	318
		DUAL	1518	762	1329	1474	674	683	1474	318
		NONE	1518	762	858	1474	674	683	1474	318

ETA722427 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA722427	REGULAR	SINGLE	1822	610	1190	1779	522	683	1779	318
		DUAL	1822	610	1420	1779	522	683	1779	318
	MESH	SINGLE	1822	610	1139	1779	522	683	1779	318
		DUAL	1822	610	1369	1779	522	683	1779	318
	NONE	SINGLE	1822	610	1101	1779	522	683	1779	318
		DUAL	1822	610	1331	1779	522	683	1779	318
		NONE	1822	610	858	1779	522	683	1779	318

ETA723027 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA723027	REGULAR	SINGLE	1822	762	1192	1779	674	683	1779	318
		DUAL	1822	762	1420	1779	674	683	1779	318
	MESH	SINGLE	1822	762	1141	1779	674	683	1779	318
		DUAL	1822	762	1369	1779	674	683	1779	318
	NONE	SINGLE	1822	762	1101	1779	674	683	1779	318
		DUAL	1822	762	1329	1779	674	683	1779	318
		NONE	1822	762	858	1779	674	683	1779	318

ETA963027 Dimensions (mm)
Model	Fan Type	Filter Type	Ext. Width	Ext. Depth	Ext. Height	Int. Width	Int. Depth	Int. Height	Face Opening Width	Face Opening Height
ETA963027	REGULAR	SINGLE	2432	762	1192	2389	674	683	2389	318
		DUAL	2432	762	1420	2389	674	683	2389	318
	MESH	SINGLE	2432	762	1141	2389	674	683	2389	318
		DUAL	2432	762	1369	2389	674	683	2389	318
	NONE	SINGLE	2432	762	1096	2389	674	683	2389	318
		DUAL	2432	762	1329	2389	674	683	2389	318
		NONE	2432	762	858	2389	674	683	2389	318

Airflow Requirements

Imperial Units (CFM)

ETA Airflow (CFM)
		HOUSE		RECIRCULATING
Enclosure	Fan Type	@100FPM	@75FPM	@100FPM	@75FPM
ETA242424	REGULAR	220	165	191	143
	MESH	N/A	N/A	191	143
	NONE	191	143	N/A	N/A
ETA243024	REGULAR	167	125	145	109
	MESH	N/A	N/A	145	109
	NONE	145	109	N/A	N/A
ETA362424	REGULAR	339	254	295	221
	MESH	N/A	N/A	295	221
	NONE	295	221	N/A	N/A
ETA363024	REGULAR	258	193	224	168
	MESH	N/A	N/A	224	168
	NONE	224	168	N/A	N/A
ETA482424	REGULAR	459	344	399	299
	MESH	N/A	N/A	399	299
	NONE	399	299	N/A	N/A
ETA483024	REGULAR	348	261	303	227
	MESH	N/A	N/A	303	227
	NONE	303	227	N/A	N/A
ETA602427	REGULAR	578	434	503	377
	MESH	N/A	N/A	503	377
	NONE	503	377	N/A	N/A
ETA603027	REGULAR	578	434	503	377
	MESH	N/A	N/A	503	377
	NONE	503	377	N/A	N/A
ETA722427	REGULAR	698	524	607	455
	MESH	N/A	N/A	607	455
	NONE	607	455	N/A	N/A
ETA723027	REGULAR	698	524	607	455
	MESH	N/A	N/A	607	455
	NONE	607	455	N/A	N/A
ETA963027	REGULAR	938	704	816	612
	MESH	N/A	N/A	816	612
	NONE	816	612	N/A	N/A

Metric Units (m³/h)

ETA Airflow (m3/h)
		HOUSE		RECIRCULATING
Enclosure	Fan Type	@0.5m/s	@0.38m/s	@0.5m/s	@0.38m/s
ETA242424	REGULAR	371	278	323	242
	MESH	N/A	N/A	323	242
	NONE	323	242	N/A	N/A
ETA243024	REGULAR	282	211	245	184
	MESH	N/A	N/A	245	184
	NONE	245	184	N/A	N/A
ETA362424	REGULAR	573	430	499	374
	MESH	N/A	N/A	499	374
	NONE	499	374	N/A	N/A
ETA363024	REGULAR	435	327	379	284
	MESH	N/A	N/A	379	284
	NONE	379	284	N/A	N/A
ETA482424	REGULAR	775	582	674	506
	MESH	N/A	N/A	674	506
	NONE	674	506	N/A	N/A
ETA483024	REGULAR	589	442	512	384
	MESH	N/A	N/A	512	384
	NONE	512	384	N/A	N/A
ETA602427	REGULAR	978	733	850	638
	MESH	N/A	N/A	850	638
	NONE	850	638	N/A	N/A
ETA603027	REGULAR	978	733	850	638
	MESH	N/A	N/A	850	638
	NONE	850	638	N/A	N/A
ETA722427	REGULAR	1180	885	1026	769
	MESH	N/A	N/A	1026	769
	NONE	1026	769	N/A	N/A
ETA723027	REGULAR	1180	885	1026	769
	MESH	N/A	N/A	1026	769
	NONE	1026	769	N/A	N/A
ETA963027	REGULAR	1586	1189	1379	1034
	MESH	N/A	N/A	1379	1034
	NONE	1379	1034	N/A	N/A

Cookie	Duration	Description
cookielawinfo-checkbox-analytics	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Analytics".
cookielawinfo-checkbox-functional	11 months	The cookie is set by GDPR cookie consent to record the user consent for the cookies in the category "Functional".
cookielawinfo-checkbox-necessary	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookies is used to store the user consent for the cookies in the category "Necessary".
cookielawinfo-checkbox-others	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Other.
cookielawinfo-checkbox-performance	11 months	This cookie is set by GDPR Cookie Consent plugin. The cookie is used to store the user consent for the cookies in the category "Performance".
viewed_cookie_policy	11 months	The cookie is set by the GDPR Cookie Consent plugin and is used to store whether or not user has consented to the use of cookies. It does not store any personal data.

Questions? 1-800-849-3429

Top Mount Series Specs

Dimensions & Face Velocity Requirements for Standard ETA Series Enclosures

Dimensions

Airflow Requirements

Products

About Us

Resources
