Drysolator™
Low Humidity & Oxygen Glovebox with
PLC Controlled Interior Environment
The Drysolator™ series provides isolation and protection against highly potent compounds. The glove box interior operates under negative pressure offering additional personnel protection in the event of a glove breach. The PLC-controlled interior reduces oxygen and humidity levels for the safe handling of reactive substances. PLC controls offer the ability to lock settings with admin-required passcodes to help avoid breaking SOPs. Third-party surrogate powder testing has proven exposure levels below 1 μg/m3, based on process and quantity*.
Process
The glovebox side can contain ISO 5 processes, while the VBE section allows a secondary cleaning station before removing equipment or material containers.
Containment
Third-party surrogate powder test shows exposure levels below 10ng/m3, even with large spills, dependent on quantity/potency*.
Design
The glovebox provides proper containment for most lab equipment, including balances, ovens, and sieves.
Benefits
Applications
This enclosure handles multiple operations. Suitable for a broad spectrum of lab OEB/Ls. Ideal for HPAPI/API applications.
HEPA Filtration & ISO 5
Features a 4” inlet HEPA filter for incoming lab air. Dual-HEPA filtration ensures pure interior air. Meets or surpasses ISO 5 standards in various conditions.
Structural Materials
The standard polypropylene structure is customizable and available in a stainless steel option. The phenolic base resists chemicals. Viewing panels come standard in acrylic with glass options available.
PLC-Controlled
The Drysolator monitors with automated programs. Door interlocks enhance containment safety. Passwords can restrict operator-specific actions.
Sanitary Fittings
Equipped with sanitary fittings for coupling. Enables integration of various powder transfer systems. Perfect for RTPs, continuous liners, and more.
Standard Sizes
The Drysolator™ comes in 5′, 6′, and 7′ widths. Units have a 30” depth and 25” interior height. Custom dimensions are available based on need.
Useful Videos
Additional Resources
Over the years, we built an inventory of unique enclosures engineered to handle specific tasks. To offer you a better experience we have gathered these enclosures on one page. Simply search by the task or equipment to find matching enclosures.
SEARCH CONTAINMENT BY APPLICATION
Over the years, we built an inventory of unique enclosures engineered to handle specific tasks. To offer you a better experience we have gathered these enclosures on one page. Simply search by the task or equipment to find matching enclosures.
Process
Designed for dispensing, weighing, and many other applications with sensitive or reactive substances that require low RH & O2 levels.
Containment
Provides safety to the operator by fully containing materials within the enclosure and maintaining sensitive materials free from contaminants.
Design
The PLC-controlled, vibration free interior allows varying sizes of equipment to be placed within the enclosure suiting many process needs.
Multi-Task Glovebox with PLC Controlled Interior Environment
Safety
The DrysolatorTM series provides containment and protection of highly potent compounds in a glovebox workstation under negative pressure to ambient. Controlled interior environment allows low oxygen and/or humidity levels for product protection. Negative pressure design protects personnel in event of glove breach. The unit provides the operator and the application the highest level of safety available.
ISO 5 INTERIOR CLEANLINESS
The side mounted HEPA filter inlet creates a clean interior working environment that meets or exceeds ISO 5 for clean processing work while in ambient or low RH/O2 environments.
HEPA FILTRATION
The DrysolatorTM contains a 4” HEPA filter inlet that allows the introduction of clean air into the glovebox. Primary and secondary 4” HEPA outlet filters then clean and exhaust the air to the house exhaust system or recirculated into the lab.
FRONT LIFT DOOR
The pneumatic-assisted hinged door opens creating a large face opening in the glovebox to facilitate equipment loading and decontamination.
STRUCTURAL MATERIALS
The standard polypropylene superstructure is customizable and available in a stainless steel option. The chemically resistant phenolic base offers a dished edge to maintain spills and protects the work surface from harmful chemicals. The viewing panels are available in glass or acrylic options.
Sizing & Options
The DrysolatorTM is available in 5’, 6’ and 7’ standard width options. All units are 30” deep with a 25” internal height. Our custom engineering and design process offers customization of size, materials of construction, and more.
Question or need a quote?
Contact us using our online form, live chat, or call 1-800-849-3429. We're here to help you find the solution you need.
Contact Our Experts
SEARCH CONTAINMENT BY APPLICATION
Build Options
| Product Type | Style | Material | Ext. Width | Ext. Depth | Internal Height | Base | Exhaust / Filtration | Voltage / Filter / Alarm | Options |
|---|---|---|---|---|---|---|---|---|---|
| E – Enclosure | D – Drysolator | P – Poly (Acrylic viewing panels) | 60" | 30" | 25" | A – Standard | B – Fab/BIBO | D – 110-120v 50-60Hz/HEPA Filter/Integrate Alarm | 0 – Pass Thru Left, Filter Right |
| G – Poly (Glass viewing panels | 72" | E – 4" Tri-Clover Male | F – 220-240v50-60Hz/HEPA Filter/Integrated Alarm | 1 – Pass Thru Right, Filter Left | |||||
| F – No Base (must be purchased separately) |
Accessories
| Side Port Options | ||
|---|---|---|
| Blank Plate | No side port needed |
|
| Continuous Liner | Designed to eliminate cross contamination of powders, protecting the person, plant, and product. Long lengths of pre-packaged liners reduce operator labor. |
|
| RTP Alpha Port | Accommodates a 105mm RTP Alpha port for connecting various betas or other containers. |
|
| Transfer Box | Polypropylene construction with access door to move materials in/out of the enclosure. |
|
| Customized Master Port | The blank plate can be customized to install iris ports, services, transfer systems, and more. |
|
| Add-Ons | ||
|---|---|---|
| Berkshire Cleaning Kit | Contact Flow Sciences for kit description |
|
